MODEL PWQ1000

APPLICATION
PWQ is self priming pump for the transport of clean or slightly dirty water for pools with large pre-filter, which, to-gether with its excellent hydraulic per-formance, gives a very large filteringcapacity.A filter with a transparent, polycarbonatelid that easily allows inspection of the in-terior of the pre-filter sieve.No possible electrical contact with the water as no part of the motor is in open toit.
PUMP
Plastic pump body
Float switch ensures automatic cut-in and cut-out -Max.
 liquid temperature: +35°c -Max.
 immersion depth: 7 m -Max.
diameter of particle: 35 mm
MOTOR
-C&u bearing
-Motor with copper winding
-Built-in thermal protector for single phase
-Insulation class: F
-Ingress Protection: IPX8
-Max.ambient temperature: +40°c
-Wide range voltage design(160V~230V)
-Other voltages or 60 Hz be available at reques

6M CABLE WITH FLOAT SWITCH
