SUITABLE  for transferring liquids of low viscosity, non-inflammable and non-explosive, not containing solid particles or fibers
• Water supply & drainage for high-rise buildings, filtration and transfer at waterworks, pressure boosting in main pipe
• Washing and cleaning systems, boiler feeding, cooling water circulation, water treatment systems, auxiliary system, support equipment
• Ultra-filtration systems, reverse-osmosis systems, distillation systems, separators, swimming pools
• Agricultural irrigation: sprinkler irrigation, drip-feed irrigation
• Food & beverage industry
• Fire-fighting system
Operating Conditions
• Low viscosity, non-inflammable and non-explosive liquids not containing solid particles or fibers. The liquids must not chemically attack the pump materials. When pumping liquids with a density or viscosity is higher than that of water, a motor with a higher output power rating shall be used.
• Liquid temperature: -20°C~+120°C
• Flow ranges: 0.7-240 m3/h
• Liquid pH value: 4-10
• Max. ambient temperature: +40°C)
• Max. operation pressure: 33 bar
• Altitude: up to 1000 m
